Peristaltic Tube Pump GD200‑1B | 200 rpm
The GD200‑1B is a tubing pump from the GD series designed for precise and reproducible dispensing and transfer processes up to 200 rpm. This compact peristaltic pump is ideally suited for laboratory, industrial, and OEM applications that require controlled flow rates, easy operation, and flexible system integration.
- Speed range 0.01–200 rpm for fine dispensing and continuous pumping
- 5″ color touchscreen with intuitive, color‑coded user interface
- Operating modes Continuous · Time · Volume for versatile applications
- Comprehensive calibration functions (flow and volume calibration, optional auto‑calibration with flow meter)
- Optional closed‑loop control with flow meter for increased process reliability
- Flexible integration via external signals, foot switch, or hand dispenser
Compatible with the DG pump head series for multi‑channel operation with up to 24 channels.
about 2-3 weeks
Only %1 left
Article no
GD200-1B
937.25 €
| Feature | GD200‑1B |
|---|---|
| Pump Type | General Dispensing Pump |
| Channels | Single channel |
| Speed Range | 0.01 – 200 rpm |
| Dispensing Volume | 0.001 – 9,999 (units: µL, mL, L) |
| Dispensing Counter | 0 – 999,999 (0 = unlimited) |
| Interval Time | 0.1 s – 9,999 h |
| Run Time | 0.1 s – 9,999 h |
| Speed Resolution | 0.01 rpm (< 100 rpm), 0.1 rpm (≥ 100 rpm) |
| Speed Accuracy | ± 0.1% |
| Operating Modes | Continuous · Time · Volume (color‑coded) |
| Display | 5″ color LCD |
| Operation | Touchscreen + physical buttons |
| Flow Direction | Clockwise and counter‑clockwise |
| Calibration Functions | Flow calibration, volume calibration, auto‑calibration with optional flow meter |
| Voice Control | Start / Stop / Pause / Direction change / Full speed |
| Control Options | Touch & buttons · Foot switch / Hand dispenser · External signals · Communication protocol |
| Closed‑Loop Control | Optional with flow meter |
| Recipes | Up to 100 storable parameter sets |
| User Management | Three levels (Administrator / Developer / Operator) |
| Log Recording | Up to 4,000 entries, exportable |
| Timed Start | Countdown & start at preset time |
| Keypad & Display Lock | Activatable |
| Noise Level | ≤ 50 dB(A) |
| Protection Rating | IP32 |
| Dimensions (L × W × H) | 305 × 190 × 201 mm |
| Weight (Drive) | approx. 3.5 kg |
| Power Supply | AC 100–240 V, 50/60 Hz |
| Power Consumption |
30 W |
| Pump Head | Tubing | Max. Flow Rate (mL/min) |
|---|---|---|
| YZ1515X (3‑roller) | 13# · 14# · 19# · 16# · 25# · 17# · 18# | 730 @ 200 rpm |
| YZ1515X (6‑roller) | 13# · 14# · 19# · 16# · 25# · 17# · 18# | 320 @ 200 rpm |
| YZ2515X | 15# · 24# | 530 @ 200 rpm |
| YZ15‑13X (YZ II 15) | 13# · 14# · 19# · 16# · 25# · 17# · 18# | 730 @ 200 rpm |
| YZ25‑13X (YZ II 25) | 15# · 24# · 35# · 36# | 1,000 @ 200 rpm |
| DMD15‑13 | 13# · 14# · 19# · 16# · 25# | 690 @ 200 rpm |
| FG15‑13 | 13# · 14# · 19# · 16# · 25# · 17# · 18# | 800 @ 200 rpm |
| FG25‑13 | 15# · 24# | 730 @ 200 rpm |
| PFH01 | ID 0.5–3.2 mm · Wall thickness 1.6 mm | 90 @ 200 rpm |
| PFH02 | ID 0.6–4.8 mm · Wall thickness 2.4 mm | 523 @ 200 rpm |
| DG‑1/2/4/6/8/12/16/24 (6‑roller) | ID ≤ 3.17 mm · Wall thickness 0.8–1.0 mm | 48 @ 100 rpm |
| DG‑1/2/4/6/8/12/16/24 (10‑roller) | ID ≤ 3.17 mm · Wall thickness 0.8–1.0 mm | 32 @ 100 rpm |
| DG15‑24 | 16# · 25# · 17# | 600 @ 200 rpm |
| DG15‑28 | ID ≤ 3.17 mm · Wall thickness 0.8–1.0 mm · 13# · 14# | 75 @ 100 rpm |
| DG15‑48 | ID ≤ 3.17 mm · Wall thickness 0.8–1.0 mm · 13# · 14# | 75 @ 100 rpm |
